SINGLE COUNTERBALANCE VALVE IN-LINE FOR OPEN CENTER VBZG (OLEOWEB, ИТАЛИЯ)

OVERCENTER VALVE SIMPLE EFFECT NOT COMPENSATED IN-LINE INSTALLATION

The counterbalance valves (or overcenter) have the task of supporting suspended loads and controlling their movement. The VBZG series includes acting valves with fixed setting flangeable on the cylinder.

DESCRIPTION

The Oleoweb valves of the VBZG series are double counterbalance valves, suitable for the management and control of the movement of a hydraulic actuator subject to bidirectional loads. They are valves with a flanged surface that allows installation directly on the cylinder. For connection to the distributor, there are GAS threaded ports in sizes from BSPP 3/8 "to BSPP 1/2" for recommended operating flows up to 60 lpm (15,9 gpm). The fixed setting allows to optimize the installation times and avoid possible tampering with the valve setting. The VBZG is a non-compensated valve: eventual backpressures must be added to the setting of the valve. The load management takes place on the re-entry lines from the cylinder, while the delivery is possible through two check valves. Thanks to the pilot line with the relative reduction ratio it is possible to manage the gradual opening of the valve to control the movement of the actuator even in the presence of gravitational loads that do not generate pressure. The VBZG valve can also work as an anti-shock valve protecting the system and the structure connected to it from damage caused by pressure peaks. This is possible only if the system distributor has the spool with open center in neutral position. Oleoweb pays particular attention to the realization of the components that realize the hydraulic seal of the counterbalance valves, carefully verifying geometrical dimensions and tolerances, as well as testing the sealing of the assembled valve. The VBZG counterbalance valves are parts in body valves: all the components are housed inside a hydraulic manifold. This solution allows you to manage high flow rates while keeping down the overall dimensions. Body and external components are made of zinc-plated steel. The zinc-nickel treatment is available on request to improve corrosion resistance. Thanks to the steel body it is possible to work with operating pressures up to 350 bar (5075 PSI).

Компания Oleoweb (Италия) производит гидравлические комплектующие: гидрозамки, предохранительные и обратные гидроклапаны, гидравлические клапаны последовательности, тормозные гидроклапаны, ручные гидронасосы, диверторы гидравлические, шаровые краны высокого давления, гидравлические плиты CETOP для гидрораспределителей и многое другое. В нашем магазине гидравлики можно купить со склада или заказать любую продукцию Oleoweb по низким ценам. Осуществляем оперативную доставку гидрокомпонентов Oleoweb по всей России.
